Obróbka deski do wiatrownicy panelowej
SET ITEM

Barge board for panel barge flashing

Standard sheet metal work, including the barge board for the panel barge flashing made of coated sheet metal, protects the board or ridge rafter from the elements.
NOTE: This type of barge flashing is part of the modular barge flashing kit available in our product lineup.

Product Description

schemat domu, dachy, obrobki blacharskie

Verge flashings

Gable flashings are installed along the side edges of the roof where they meet the building’s gable walls. Their main function is to protect these edges from the elements, such as wind and rain. These flashings prevent the roof covering from being lifted by the wind and protect against leaks along the side edges. Gable flashings are typically made of sheet steel matched to the color and style of the roof coverings. In addition to their protective function, gable flashings provide an aesthetic finish to the side edges of the roof and are often integrated with elements of the building’s facade.

Barge board for panel barge flashing

The barge flashing is a finishing element of the roof surface that supports the roof drainage system. It is installed next to the barge flashing and facilitates the drainage of water from the edges of the roof; for this reason, it is called a barge flashing gutter. The barge board for panel barge flashing is a dedicated component of the installation kit, which consists of three products; the other two are: the panel barge flashing and the drainage gutter for the panel barge flashing. The barge flashing is symmetrical and can be used with both the right- and left-side panel barge flashings . It ensures the barge flashing is properly positioned while guaranteeing a watertight seal with the roof coverings.

Wiatrownica panelowa

Ten produkt pasuje do:

Wiatrownica panelowa

Zobacz ofertę
Choose a coating:
More information about coatings
PURMATmatte polyurethane *

Technical specification of the coating

coating thickness
50 µm
corrosion resistance
High ★★★★
UV resistance
High ★★★★
machinability
High ★★★☆
aesthetic warranty
up to 30 years
technical warranty
50 years

Available colours

PUM RR 033
PUM R033
PUM RR 750
PUM R750
PUM RAL 7016
PUM RAL 7016
PUM RAL 8017
PUM RAL 8017
TOPMATmatte polyester (Arcelor)

Technical specification of the coating

coating thickness
35 µm
corrosion resistance
High ★★★★
UV resistance
High ★★★★
possibility
High ★★★☆
aesthetic warranty
20 years
technical warranty
35 years

Available colours

TOPMAT RR 033
TOPMAT R033
TOPMAT R750
TOPMAT R750
TOPMAT RAL 7016
TOPMAT RAL 7016
TOPMAT RAL 8017
TOPMAT RAL 8017
The Pruszyński Company guarantees that each individual order will be fulfilled in the same color (shade). However, due to the complexity of the coating processes, slight variations in shade may occur between individual shipments. Therefore, liability for color consistency is limited to a single shipment.

* The modular barge flashing is available only with PURMAT and TOPMAT coatings. Please note that it will appear visually consistent only when the panels are coated with the same coating and color. In the case of other coatings, such as PMG35 or ULTRAMAT, even though they are matte, some differences in shade may occur, even for the same color.

Other items in this category

Inspiration

One-storySingle-family home

Single-family home in Wola Rzędzińska

TIGRA Metal Roof Tiles — the perfect solution for homeowners looking for a flat roof surface

One-storySingle-family home

Single-family home in Wola Rzędzińska

REN Metal Roof Tile

Single-family home

Single-family home in Białystok

REGLE Roof Panels

One-storySingle-family home

Single-family home in Końskie

REN metal roof tiles combine durability and aesthetics

One-storySingle-family home

Single-family home in Rytwiany

MODUS Metal Roof Tile

Multi-storySingle-family home

Single-family home in Ostrava

PD-510 Standing Seam Roof Panels

Commercial Investments

University Sports Center in Rzeszów

University Sports Center in Rzeszów

Single-family home

Single-family home in Stąporków

MODUS Metal Roof Tile

Commercial Investments

Orientarium, Łódź Zoo

The Breeding and Exhibition Orientarium Building at the Łódź Zoo

Single-family home

A single-family home in the village of Tumlin

MODUS Metal Roof Tile

Multi-storySingle-family home

Single-family home in the village of Przeczów

OPTIMA Metal Roof Tile

Commercial Investments

Car dealership in Mikołów

BMW M Dealership in Mikołów

One-storySingle-family home

A single-family home and a garden shed in Wola Rzędzińska

SZAFIR Metal Roof Tile

Multi-storySingle-family home

Two-story single-family home in Józefów

STAND-UP SEAM ROOF PANELS

One-storySingle-family home

Single-family home in Bydgoszcz

STAND-UP SEAM ROOF PANELS

Commercial Investments

Polonez Plus in Kielce

The Polonez Plus manufacturing plant in Kielce

Commercial Investments

Pex-Pool Plus Dębica

Pex-Pool Plus Dębica

Commercial Investments

"Dwór Dobarz" Guesthouse

REGLE roof panels, imitation wood shingles, Zakopane style

One-storySingle-family home

Single-family home in Stąporków

The PŁASKA PLUS metal roof tile is an excellent choice for modern construction, and its flat surface is very popular among developers.

One-storySingle-family home

Single-family home in Wymysłowo

The RUBIN metal roof tile is a harmonious blend of classic style and functionality.

One-storySingle-family home

Single-family home in Białystok

A classic with a modern twist. FIORD metal roof tiles used to cover a single-story house with a modern design.

Single-family home

Single -family House Tuczępa

Single-family home

A single -family house in Rytwiny

Single-family home

Single -family house, Staszów

Single-family home

Villa Niepołomice

Single-family home

Arkadia Investment housing estate

Commercial Investments

Sevilla Gold Hotel

Single-family home

Single-family home, Pliskowola

Commercial Investments

Arena Grupa Azoty in Puławy

Commercial Investments

Kielce Bus Station

Avant-garde design in a public building

Single-family home

A single -family house in Rudna near Rzeszów

Flat metal sheet, single -family house in Rudna

Single-family home

Gable-roofed house in Końskie

Commercial Investments

Flat metal tile market, Orzysz

Single-family home

Trapeze

Single-family home

Modus

Single-family home

Detached house complex roof. Modus roof tile

Modus metal roof tile, multi -track roof

Commercial Investments

Mercedes

Mercedes

Commercial Investments

Leroy Merlin

Leroy Merlin

Technical specification

Technical Information

Convenient connections to:
Modular barge flashing
Length:
2 meters
Thickness:
0,50
Coating
PURMAT (4 color options)
TOPMAT (4 color options)
obróbka deski do wiatrownicy panelowej

Table of Finishes: Availability and Applications

Downloads

Profil produkcji
[PDF]
File version: 26.11

Do you have any questions?

Jakie obróbki do blachodachówki?
Podstawowe obróbki do blachodachówki modułowej to: wiatrownica panelowa, wiatrownice górne i boczne, gąsiory Omega i Baryłkowe, łaty okapowe wentylacyjne, rynny koszowe, obróbki przyścienne, pasy podrynnowe, pasy nadrynnowe i rynienki odpływowe. Wszystkie obróbki dostępne w naszej ofercie, znajdziecie Państwo pod tym linkiem: TYPOWE OBRÓBKI BLACHARSKIE
Czy dach wymaga konserwacji?
Tak, każdy dach wymaga okresowych przeglądów celem sprawdzenia czy nie pojawiły się jakieś uszkodzenia. Większość produktów oferowanych przez firmę Blachy Pruszyński ma dostępne różnego typu specjalistyczne powłoki (objęte gwarancją), zwiększające żywotność i trwałość pokryć blachowych. Konserwacja polega głównie na usunięciu nalotów i pyłów kominowych, które pozostawione przez dłuższy okres czasu mogą prowadzić do uszkodzenia blachy. Szczególną uwagę należy zwracać na miejsca wokół kominów, które są newralgiczne, ze względu na bardziej wymagające warunki eksploatacji. Jeżeli podczas przeglądu pokrycia, zauważone zostaną miejscowe uszkodzenia w powłoce lakierniczej należy wykonać korekty malarskie. W takich sytuacja najlepszym rozwiązaniem jest skorzystanie z dedykowanych farb zaprawkowych dopasowanych do danej powłoki. Farby takie są w ciagłej ofercie Blachy Pruszyńskiej i zdecydowanie zaleca się wykorzystanie firmowych produktów, rekomendoawnych do danej powłoki.
Czy jest możliwe wykonanie miedzianych obróbek przy dachu stalowym?
Przy stosowaniu miedzi należy uważać, gdyż tlenki miedzi są bardzo agresywne i powodują korozję innych metali. Dlatego też na na budynkach nie można łączyć jej z innymi gatunkami metali (miedź wchodzi w reakcje kontaktową i powoduje korozję elektrolityczną innych metali).
Czy podczas cięcia arkuszy można używać szlifierki kątowej?
Nowoczesne pokrycia dachowe wykluczają użycie szlifierek kątowych do cięcia. Użycie takiego sposobu cięcia materiału wiąże się z utratą gwarancji.
Szlifierka kątowa podczas pracy i cięcia wytwarza bardzo duże ilości ciepła, a to z kolei uszkadza krawędzie blachy, a także pokrywającą ją powłokę. Dodatkowo wydobywające podczas pracy opiłki, wtapiają się w powierzchnię blachy, tworząc dodatkowo potencjalne ogniska korozji.
Właściwym sposobem cięcia blachy, jest zastosowanie automatycznych nożyc skokowych (tzw. nibler) lub nożyc ręcznych. Wykorzystują one siłę mechaniczną do przecięcia blachy, nie narażając jej na wysokie skoki temperatury. Dodatkowo warto pamietać, że po zakończonym cięciu dobrze jest zabepieczyć cięte miejsca dedykowanym lakierem ochronnym lub specjalną farbą.
Dlaczego blachodachówka polecana jest przy remontach starych dachów?
Jest to bezpośrednio związane z jej niewielkim ciężarem. W wypadku starych dachów więźby remontowanych domów często są już nieco nadszarpnięte przez czas. Dlatego bezpieczniej jest zastosować blachodachówkę, której waga oscyluje na poziomie 4,7 kg/m2, niż prawie dziesięciokrotnie od niej cięższej dachówki ceramicznej. Natomiast zawsze warto zweryfikować stan więźby dachowej, ze specjalistą i upewnić się, czy mimo wszystko nie wymaga ona renowacji lub wymiany. W takich wypadkach bezpieczeństwo mieszkańców lub pracowników budynku, a także ekipy montażowej, jest zawsze priorytetem. W większości jednak sytuacji, stan konstrukcji bez większych problemów pozwala na wykorzystanie blachodachówki, podczas gdy zastosowanie dachówki ceramicznej, nie byłoby już możliwe.
Ile kosztuje m2 paneli elewacyjnych z blachy?
Na koszt paneli elewacyjnych wpływa przede wszystkim typ blachy z którego zostały wykonane. Zarówno jej typ, jak i powłoka. W naszej ofercie znajdą Państwo panele w dwóch szerokościach - 315mm oraz 215mm. Ceny w zależności od wyboru wariantu, znajdą Państwo w naszym cenniku. Zachęcamy także do kontaktu bezpośredniego w wypadku indywidualnych zamówień.
Jak testować skuteczność powłoki na blachodachówkę?
Samodzielnie nie jesteśmy w stanie testować skuteczności powłoki blachodachówek. Jednak wybierając produkty Blachy Pruszyński, możemy być pewni, że przeszły one rygorystyczne kontrole, ponieważ firma dysponuje własnym laboratorium oraz współpracuje z krajowymi i zagranicznymi jednostkami badawczymi, aby spełnić najwyższe kryteria jakościowe.
