Technical specification

General information

Installation : roof panels for seams should be mounted at positive temperatures. Pruszyński sheets allow a different assembly method, consistent with roofing art.


Effective width
510 mm

Seam high
25 mm

Material
S 250 GD + Z 200 or 275
Max. recommended length of sheet
7 mb
Min. length of sheet
0,5 mb
Thickness
0,50 / 0,70 mm
Covering
polyester glossy, polyester matt, PURLAK, PURMAT
Accessories
Screws, nails, sealing tapes, flashings
Appliance
covering of roofs with minimal slope 8o (14%)
Panel PD510 T-S - przekroj

Recommendations

Panels storage

Packages should be stored in dry and well-ventilated spaces, without humidity condensation  between the sheets. Collective packages should be put on blocks about 20cm height upon the surface. If panels are stored more than 3 weeks from the production date – panels should be checked and separators should be put between to allow for free air circulation. All information about the way and period of storage are on the protective foil, product labels and our catalogues, assembly instructions and website.

Protective foil

Protective foil is used to safe the roof panels against mechanical damages. It should be removed directly at the assembly stage and it should protect panels against humidity and sun during the storage period. Non compliance with above rules may cause difficulties when removing the foil from sheets and dirty after the glue.

Maintance

Generally, roofs with standing seam panels do not demand any special maintenance. Nevertheless, so as to prevent the risk of to fast damaging of the building and regardless the localization, wall covering and roof covering must be checked and maintenanced once a year, at least. Deposit, industrial dust (from lime plants, cement limes, foundries and mines) which cause damage of varnish cover as a result of chemical reaction with water and leafs, which cause fading of organic cover due to rotting should be removed from panel surface. Any lack  in covering should be cleaned and painted with special touch-up paints.

Final warnings

1. Special electric vibrating scissors or irregular, nibblers and hand scissors should be used to cut sheet.  Tools which cause damage of varnish and galvanized covering due to the produced heat when cutting the steel are forbidden, for instance angle grinder.

2. You can walk on the roof with shoes with soft bottom, make steps in the bottom of waves, on patches. Before you start walking on the roof, all the screws must be assembled.

3. Small damages of covering from assembly could be painted with touch-up paints. The surface must be cleaned from dirt and oil.

4. Steel chips from the cutting or drilling must be removed with soft brush – its rusting may damage the steel surface.

5. Dirt, which stays after assembler work or dirt from daily exploitation should be removed with normal cleaning agents.

6. Use of any steel treatments (including chimney cap, rainwater cleaner, etc.) from copper sheets on roofs and elevations from galvanized and covered sheets is forbidden.

Choose a coating:
Więcej informacji o powłokach
PURMATpolyurethane, matt

Technical specification of the coating

thickness of layer
50 µm
corossion resistance
High ★★★★
UV resistant
High ★★★★
possibility of bending
High ★★★☆
aesthetic warranty
up to 30 years
technical warranty
50 years

Available colours

PUM R011
PUM R011
PUM R028
PUM R028
PUM RR 033
PUM R033
PUM RR 750
PUM R750
PUM RAL 7016
PUM RAL 7016
PUM RAL 8017
PUM RAL 8017
PURLAKpolyurethane, glossy

Technical specification of the coating

thickness of layer
50 µm
corossion resistance
High ★★★★
UV resistant
High ★★★☆
possibility of bending
High ★★★☆
aesthetic warranty
do 30 years
technical warranty
50 years

Available colours

PU RAL 7016
PU RAL 7016
PU RAL 9005
PU RAL 9005
ULTRAMAT®poliyester, matt (Arcelor PL)

Technical specification of the coating

thickness of layer
35 µm
corossion resistance
High ★★★☆
UV resistant
Good ★★☆☆
possibility of bending
Good ★★☆☆
aesthetic warranty
15 years
technical warranty
35 years

Available colours

PMG R011
PMG R011
PMG R028
PMG R028
PMG R032
PMG R032
PMG R033
PMG R033
PMG R750
PMG R750
PMG RAL 7016
PMG RAL 7016
PMG RAL 8017
PMG RAL 8017
PS25poliyester, glossy

Technical specification of the coating

thickness of layer
25 µm
corossion resistance
High ★★★☆
UV resistant
Good ★★☆☆
possibility of bending
Good ★★☆☆
aesthetic warranty
10 years
technical warranty
30 years

Available colours

R028
R028
R032
R032
RAL 1002
RAL 1002
RAL 1015
RAL 1015
RAL 1021
RAL 1021
RAL 3000 probka koloru
RAL 3000
RAL 3005
RAL 3005
RAL 3011
RAL 3011
RAL 3016
RAL 3016
RAL 5010
RAL 5010
RAL 6005
RAL 6005
RAL 6029
RAL 6029
RAL 7000
RAL 7000
RAL 7016
RAL 7016
RAL 7024
RAL 7024
RAL 7035
RAL 7035
RAL 8004
RAL 8004
RAL 8017
RAL 8017
RAL 9002
RAL 9002
RAL 9005
RAL 9005
RAL 9006<br><span style="font-size: 7pt;">SILVER</span>
RAL 9006
SILVER
RAL 9007<br><span style="font-size: 7pt;">SILVER METALLIC</span>
RAL 9007
SILVER METALLIC
RAL 9010
RAL 9010
R028
R028
R032
R032
RAL 1002
RAL 1002
RAL 1015
RAL 1015
RAL 1021
RAL 1021
RAL 3000 probka koloru
RAL 3000
RAL 3005
RAL 3005
RAL 3016
RAL 3016
RAL 5010
RAL 5010
RAL 6005
RAL 6005
RAL 6029
RAL 6029
RAL 7000
RAL 7000
RAL 7016
RAL 7016
RAL 7024
RAL 7024
RAL 7035
RAL 7035
RAL 8004
RAL 8004
RAL 8017
RAL 8017
RAL 9002
RAL 9002
RAL 9005
RAL 9005
RAL 9006<br><span style="font-size: 7pt;">SILVER</span>
RAL 9006
SILVER
RAL 9007<br><span style="font-size: 7pt;">SILVER METALLIC</span>
RAL 9007
SILVER METALLIC
RAL 9010
RAL 9010
RAL 1002
RAL 1002
RAL 3011
RAL 3011
RAL 3016
RAL 3016
RAL 5010
RAL 5010
RAL 6029
RAL 6029
RAL 7016
RAL 7016
RAL 7035
RAL 7035
RAL 8017
RAL 8017
RAL 9002
RAL 9002
RAL 9006<br><span style="font-size: 7pt;">SILVER</span>
RAL 9006
SILVER
RAL 9007<br><span style="font-size: 7pt;">SILVER METALLIC</span>
RAL 9007
SILVER METALLIC
RAL 9010
RAL 9010
Pruszyński Company guarantess realization of each order in one colour shade. Although due to technological process of covering paint to steel shets there is possibility for occuring difference in colour shade in different deliveries.

Regarding this please inform sales person if different delivery is continuation of previous orders.

Product description

Dom jednorodzinny z tarasem i altaną. Dach, panel dachowy na rąbek

Roof panels for the drum

Sheets on the so -called Standing seam is one of the oldest technologies used in construction.

Now we can propose a modern solution in the traditional shape of sheets with standing sheet metal for years.

The edge finish option with cut edges enabling assembly on the start strip.
