Karta produktu
Optima roof tile
OPTIMA - Custom roof tile
Technical specification
General information
length of module:
350 mm
height of bending:
25 mm
height of profile:
35 mm
effective width:
1080 mm
total width:
sheet thickness
max. recommended length of sheet:
5315 mm
min. length of sheet:
min. slope of roof:
9°
Length of full module sheets
| Number of modules | length of sheet – OPTIMA 350/25 |
|---|---|
| 2 | 0,765 |
| 3 | 1,115 |
| 4 | 1,465 |
| 5 | 1,815 |
| 6 | 2,165 |
| 7 | 2,515 |
| 8 | 2,865 |
| 9 | 3,215 |
| 10 | 3,565 |
| 11 | 3,915 |
| 12 | 4,265 |
| 13 | 4,615 |
| 14 | 4,965 |
| 15 | 5,315* |
| 16 | 5,665 |
| 17 | 6,015 |
| 18 | 6,365 |
| 19 | 6,715 |
| 20 | 7,065 |
* – maksymalna zalecana długość arkusza
Recommendations
Transport and storage
- If the customer collects the product with his own means of transport, the vehicle shall have an open loading platform allowing for easy loading and unloading, with the length suitable for ordered sheets. The sheets shall not extend beyond the platform. Proper anchoring of the sheet packages for the transport will reduce the damage of the sheet paint coat due to abrasion.
- It is of course the best to unload in original manufacturer packaging , using mechanical unloading equipment.
- Unloading shall be carried out by the proper number of people, that is in the case of long sheets (ca. 6 linear metre) the sheets shall be unloaded by 6 people, three on each side. Special attention shall be paid not to friction one sheet against the other, bend the side edges or stretch the sheet. Steel sheet deformation during the unloading and moving can result in problems with proper installation (chinks in clamps).
- Protective foil is used to safe the roof panels against mechanical damages. It should be removed directly at the assembly stage and it should protect panels against humidity and sun during the storage period. Non compliance with above rules may cause difficulties when removing the foil from sheets and dirty after the glue.
- If the customer collects the product with his own means of transport, the vehicle shall have an open loading platform allowing for easy loading and unloading, with the length suitable for ordered sheets. The sheets shall not extend beyond the platform. Proper anchoring of the sheet packages for the transport will reduce the damage of the sheet paint coat due to abrasion.
- It is of course the best to unload in original manufacturer packaging , using mechanical unloading equipment.
- Unloading shall be carried out by the proper number of people, that is in the case of long sheets (ca. 6 linear metre) the sheets shall be unloaded by 6 people, three on each side. Special attention shall be paid not to friction one sheet against the other, bend the side edges or stretch the sheet. Steel sheet deformation during the unloading and moving can result in problems with proper installation (chinks in clamps).
- Protective foil is used to safe the roof panels against mechanical damages. It should be removed directly at the assembly stage and it should protect panels against humidity and sun during the storage period. Non compliance with above rules may cause difficulties when removing the foil from sheets and dirty after the glue.
Maintenance and washing
- In order to extend durability of roofs and elevations it’s recommended to check and conservative it.
- Inspection – One time a year (it’s best in spring) there should be inspection of roof/elevation in order to early detection of possible damage.
- Cleaning of steel sheet – Roof and elevation made of steel sheets require cleaning at least once a year. Stratifying dirt on steel sheet may cause uneven discoloration of lacquer (because of uneven impact of UV beams), and lower protection to corrosion(dust traps humidity on steel sheets which causes damage). Dirty and stained spots can be cleaned by soft brush and water (temp. max. 60c). If it is necessary it is permitted to use some light detergent (ph 6/7, max 10% solution). There also can be used pressed water(max. 100bar) to cleaning, however the beam of water cannot be applicated too near of surface of sheets(min. 30 cm), also it shouldn’t be perpendicularly to surface. Near the connections water beam should be directed to bottom, to avoid water of entering cracks near connections. With old surfaces of steel sheets we should deal with high cautiously. Cleaning should be conducted from top to bottom, and cleaned spots should be rinsed out immediately.
- It is not permitted to use scouring powders, nitro solvent, chlorine liquor, aromatised substances, substances with Amon chloride or sodium.
- Damages – Possible damages during guarantee should be consulted with Contractor of roof/elevation and can be repaired only with his written permission.Repair of damages on small surfaces is done with quick-drying varnish. However painting big surfaces should be done with special industrial paints to renovating coverings. Painting should be limited only to special damaged spots (scratches to steel, centres of corrosion etc.)Preparation of surface to painting should be done with generally accepted rules. It is necessary to precisely remove all signs of corrosion – best with special brush or close-grained sandpaper. Then that surface should be undusted, degreased and cleaned. To degrease extraction naptha or water with addition of surfactant(best with 1-2%solution of ammoniac) can be used. Repaired spots may be different in colour compared to original steel sheets because of natural impact of atmospheric phenomenon (ageing of varnish due to impact of UV radiation)
- ATTENTION!– During inspecting, cleaning, conservation and repair all work safety regulations should be obeyed.Pruszyński Sp. z o.o. is not in charge of possible accidents during carrying out all following actions.
- In order to extend durability of roofs and elevations it’s recommended to check and conservative it.
- Inspection – One time a year (it’s best in spring) there should be inspection of roof/elevation in order to early detection of possible damage.
- Cleaning of steel sheet – Roof and elevation made of steel sheets require cleaning at least once a year. Stratifying dirt on steel sheet may cause uneven discoloration of lacquer (because of uneven impact of UV beams), and lower protection to corrosion(dust traps humidity on steel sheets which causes damage). Dirty and stained spots can be cleaned by soft brush and water (temp. max. 60c). If it is necessary it is permitted to use some light detergent (ph 6/7, max 10% solution). There also can be used pressed water(max. 100bar) to cleaning, however the beam of water cannot be applicated too near of surface of sheets(min. 30 cm), also it shouldn’t be perpendicularly to surface. Near the connections water beam should be directed to bottom, to avoid water of entering cracks near connections. With old surfaces of steel sheets we should deal with high cautiously. Cleaning should be conducted from top to bottom, and cleaned spots should be rinsed out immediately.
- It is not permitted to use scouring powders, nitro solvent, chlorine liquor, aromatised substances, substances with Amon chloride or sodium.
- Damages – Possible damages during guarantee should be consulted with Contractor of roof/elevation and can be repaired only with his written permission.Repair of damages on small surfaces is done with quick-drying varnish. However painting big surfaces should be done with special industrial paints to renovating coverings. Painting should be limited only to special damaged spots (scratches to steel, centres of corrosion etc.)Preparation of surface to painting should be done with generally accepted rules. It is necessary to precisely remove all signs of corrosion – best with special brush or close-grained sandpaper. Then that surface should be undusted, degreased and cleaned. To degrease extraction naptha or water with addition of surfactant(best with 1-2%solution of ammoniac) can be used. Repaired spots may be different in colour compared to original steel sheets because of natural impact of atmospheric phenomenon (ageing of varnish due to impact of UV radiation)
- ATTENTION!– During inspecting, cleaning, conservation and repair all work safety regulations should be obeyed.Pruszyński Sp. z o.o. is not in charge of possible accidents during carrying out all following actions.
PURMATpolyurethane, matt
Technical specification of the coating
Thickness of coating
50 µm
Corrosion resistance
High ★★★★
UV resistance
High ★★★★
Possibility of bending
High ★★★☆
Guarantee
Up to 30/50 years
Available colours
PUM RR 750
PUM RR 033
PUM RR 011
PUM RR 028
PUM RAL 7016
PUM RAL 8017
PURLAKpolyurethane, glossy
Technical specification of the coating
Thickness of coating
50 µm
Corrosion resistance
High ★★★★
UV resistance
High ★★★☆
Possibility of bending
High ★★★☆
Guarantee
up to 30/50 years
Available colours
PURMAXhybrid coating, satin (polyurethane & poliyester)
Technical specification of the coating
Thickness of coating
40 µm
Corrosion resistance
High ★★★★
UV resistance
High ★★★★
Possibility of bending
High ★★★☆
Guarantee
20/40 years
Available colours
RAL 8004
PMG35®poliyester, matt
Technical specification of the coating
Thickness of coating
35 µm
Corrosion resistance
High ★★★☆
UV resistance
High ★★☆☆
Possibility of bending
Good ★★☆☆
Guarantee
15/35 years
Available colours
PS25poliyester, glossy
Technical specification of the coating
Thickness of coating
25 µm
Corrosion resistance
High ★★★☆
UV resistance
Good ★★☆☆
Possibility of bending
Good ★★☆☆
Gwarancja estetyczna
10 years
Guarantee
30 years
Available colours
Product description
Roofing tile with character
Optima is a metal roof tile produced for a specific length.
The sheets are mounted classically like the other roof tiles in Blachy Pruszyński’s offer.
Optima is available in all coatings from our offer in 27 basic colors from the RAL and RR palette.
ATTENTION !!! When connecting sheets in the length, you should take the tabs – 30 mm front and 35 mm back. The sum of bookmarks for a sheet with full rear pressing is 65 mm
